In the market, Neo Impex industry has developed a good image because of offering the wide array of high quality of pipe bends to buyers. They are today globally dealing with hundreds of clients on daily basis. The organization is having the collection of the comprehensive range of Alloy Steel ASTM A234 WP11 Pipe Bends that is easily sustainable. The customers will be assured for offering product in different specifications that easily fulfill all application demands. The product to the buyer is supplied at market leading prices.
Specification-
• Standard specification- The standard specification of the ASTM A234 Alloy Steel WP11 Long Radius Bend is ASME SA234, ASTM A234, ANSI/ASME B16.28/B16.9, and MSS SP75/SP43.
• Sizes- The offered range of products size is ERW/fabricated/welded is 2” to 36” and seamless is ½” to 24”.
• Wall thickness- The W.T. of pipe bend is ranging in 3.0mm, 1.5mm, 2.0mm and customized.
• Bending angle- The product bending angle is ranging in 15⁰, 135⁰, 180⁰, 45⁰, 30⁰, 90⁰.
• Outer diameter- The OD of product ranges from 38.0mm to 206.0mm.
• Bend Radii- It is ranging in 75, 250, 100, 150, 800, 500, 300, 1500, 1200mm.
• Bending Radius- It is available in R- 1D, 10D, 2D, 6D, 8D, 3D, 5D and customized.
Testing-
In a reliable industry to supply appreciable quality of product help of various tests are taken like-
1. Hardness test
2. Flattening/flaring test
3. Macro/micro test
4. Pitting resistance test
5. Positive material identification test
6. Intergranular corrosion test
7. radiography test
8. Hydrostatic test
A buyer can surely buy the Alloy Steel WP11 Pipe Bend from us to satisfy all application desires.
Specifications : ASTM A234 & ASME SA234
Dimensions : ASME/ANSI B16.9 / B16.28 and MSS SP-43 / SP-75
Size : Seamless Pipe Bends (1/2″ – 24″), ERW / Welded / Fabricated Pipe Bends (2″ – 36″)
Outer Diameter : 38.0 mm – 206.0 mm
Wall Thickness : 1.5 mm / 2.0 mm / 3.0 mm – greater wall thickness at request
Bend Radii : 75 / 100 / 150 / 250 / 300 / 500 / 800 / 1,000 / 1,200 / 1,500 mm
Bending Radius(R): R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Bending angle (θ): 15°, 30°, 45°, 60°, 90°, 135°, 180°
| ASME Pipe Bend | ANSI B16.9, ANSI B16.28, MSS-SP-43 |
| DIN Pipe Bend | DIN2605, DIN2615, DIN2616, DIN2617, DIN28011 |
| EN Pipe Bend | EN10253-1, EN10253-2 |
| ASME B16.9 | Factory-Made Wrought Fittings Buttwelding |
| ASME B16.25 | Buttwelding Ends ASME B16.28 – Wrought Steel Short Radius Elbows and Buttwelding Returns |
| MSS SP-43 | Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications |
| Grade | C | Mn | Si | S | P | Cr | Mo |
| A234 WP11 | 0.05-0.2 | 0.3-0.8 | 0.5-1 | ≤0.030 | ≤0.030 | 1-1.5 | 0.44-0.65 |
| Grade | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation % |
| A234 WP11 | 415 - 585 | ≥205 | ≥20 |
| Alloy Steel WP11 Pipe Bend | Alloy Steel WP11 Buttweld Bend |
| Alloy Steel WP11 Mandrel Bends | Alloy Steel WP11 Long Radius Bend |
| Alloy Steel A234 WP11 Piggable Bend | Alloy Steel WP11 Hot Induction Bend |
| ASTM A234 WP11 Seamless Pipe Bend Suppliers | ANSI WP11 Welded Pipe Bend |
| Chrome Moly A234 WP11 U Pipe Bend Dealer | Alloy Steel A234 WP11 J Pipe Bend Exporter |
| Alloy WP11 Mitered Pipe Bend Stockholder | Steel WP11 3D Pipe Bend Distributors |
| Chrome Moly Alloy Steel WP11 5D Pipe Bend | A234 WP11 10D Pipe Bend Manufacturer |
| A234 WP11 Alloy Steel 2.5D Pipe Bend | WP11 Alloy Steel 22D Pipe Bend |
| Alloy Steel 11/4 Cr-1/2Mo Customized Pipe Bend | Chrome Moly Alloy A234 WP11 Bend |
| ANSI B16.9 Alloy Steel WP11 12D Pipe Bending | Alloy Steel WP11 High Pressure Bending Stockist |
| ASTM A234 Alloy WP11 180 Degree Pipe Bend | ASME SA234 Alloy Steel WP11 DIN Pipe Bend |
| Chrome Moly Alloy Steel WP11 EN Pipe Bend | WP11 Alloy Steel ASME Pipe Bend |
| A234 WP11 Small Size Pipe Bending | ASME SA234M Alloy WP11 Pipe Bend Elbow |
| Steel WP11 90 Degree Pipe Bend | A234 WP11 160 Deg Pipe Bend |
ASTM A234 WP11 Alloy Steel Pipe Bends are known to deliver exceptional performance and are generally developed for meeting the demands. We offer a broad range of ASTM A234 WP11 Alloy Steel Buttweld Bend through a worldwide network of stock-keeping branches. These ASTM A234 WP11 Pipe Bend is use in various industries like :
A Wide Range Of the Best Quality ASTM A234 WP11 Alloy Steel Pipe Bend, a234 wp11 chemical composition, astm a234 wp11, sa234 wpb material specification, a234 wp11 fittings, wp11 material, astm a234 wpb chemical composition, astm a234 wpb pdf, astm a234 wpb mechanical properties, a234 wp11 Pipe Bend price list, alloy steel wp11 Pipe Bends price, a234 wp11 Pipe bends dimensions pdf, a234 wp11 alloy steel 180 degree pipe bender, alloy steel wp11 bend dimensions, Small size pipe bending, Large size pipe bending, Butt-welded pipe bending, a234 wp11 ss 180 Degree pipe bend Manufacturer, Supplier in India.
MIDDLE EAST Saudi Arabia |
AFRICA Nigeria NORTH AMERICA Usa |
EUROPE Russia |
ASIA India SOUTH AMERICA Argentina |
We are renowned & most acclaimed Source, Stock, Distribution, Manufacturer, Suppliers, Stockholder, Traders, Wholesaler, Dealer, Distributor, Importer & Exporter, Fabricator, Stockist of ASTM A234 WP11 Buttweld Pipe Bends in Alloy Steel.
