LTCS A350 LF2 Flanges

Best Price of ASTM A350 LF2 LTCS WNRF Flanges Exporter, ASTM A350 LF2 Flanges, ASME SA350 LF2 LTCS Class 300 Flange Wholesaler, LTCS A350 LF2 Flat Flange, LTCS LF2 Industrial Flanges, Stockholder Of Low Temperature Carbon Steel RTJ Flange, Flange A350 LF2, ASTM A350 LF2 Plate Flanges, ASME SA350 LF2 LTCS Slip On Flange, ANSI B16.5 LTCS LF2 Blind Flange, ASTM A350 LF2 LTCS EN 1092-1 Flanges Traders in India.

LTCS A350 LF2 Flanges

What is the LTCS A350 LF2 Flange?

ASTM A350 LF2 flanges are generally made from low-carbon steel alloys, either forged or ring rolled. LTCS A350 LF2 Flanges are typically supplied in normalized, tempered, or quenched conditions, and they are usually used in low-temperature applications. They come in a variety of sizes, ranging from 1/2 inches to 24 inches in diameter. Its properties include maximum machinability, moderate strength and leak-proof connections. In addition, it is relatively inexpensive. ASTM A350 LF2 Flanges are made from high-quality materials that are resistant to heat and pressure. This material is commonly used in oil and gas pipelines. ASTM A350 LF2 Flanges and Carbon Steel A105 Flanges are used in low temperature, ambient, and high-temperature applications. They are available in a variety of sizes and are zinc plated or oil black. They can be welded or threaded. They are also corrosion-resistant. ASTM A350 LF2 Flanges and High Yield CS A694 Flanges have different configurations, with a welded neck or flat face. A welded neck offers extra grip and is more expensive than a plain flange. They are commonly used to connect vessel openings and piping. They are also very reliable and safe, and are ideal for high-temperature applications.

ANSI B16.5 LTCS Orifice Flanges, BS10 Table D, Table E, A350 LF2 Weld Neck Flanges, DIN Standard Flanges, LTCS LF2 Flanges, A350 LF2 LTCS Flange, Carbon Steel ASTM A350 LF2 LTCS Pipe Flanges, Stockist of LTCS Slip On Flanges, Global Supplier of A350 LF2 LTCS Weld Neck Flange, ANSI B16.47 LTCS A350 Threaded Flange, ANSI B16.48 A350 LF2 LTCS Forged Flange, A350 LF2 LTCS BS 10 Socket Weld Flange, Carbon Steel A350 LF2 Low Temperature Blind Flanges Dealer in India.

For three decades, Neo Impex Stainless Pvt. has provided the industry with best quality LTCS A350 LF2 Flanges through outstanding products and exceptional service. We use premium resources, dependable technology, and machinery to produce all our goods. As an ISO-certified company, we maintain the highest standards of quality and safety are devoted to precision. We are manufacturers, suppliers, and exporters of LTCS A350 LF2 Flanges made from Low-Temperature Carbon Steel compliant with ASTM A350 specifications. They are adept at working at low-temperature services. Our LTCS A350 LF2 Orifice Flanges have a yield strength of 36 ksi and are normalized to gain a good grain structure. We effectively connect equipment with nozzles used in intensive applications industries like light and heavy chemical manufacturing factories. Low-pressure flanges provide maximum machinability when annealed, normalized, or forged. Our LTCS A350 LF2 Slip-On Flanges possess moderate strength and offer a leakage-proof connection at a low cost.

The hydrocarbon, steam and general industrial services which work at sub-zero temperatures use LTCS A350 LF2 Weld Neck Flanges which are easiest to bolt. Also We offer wide range of LTCS ASTM A350 LF2 Flanges such as ASTM A350 LF2 LTCS Slip On Flanges, LTCS LF2 Weld Neck Flanges, LTCS LF2 Socket Weld Flanges, A350 LF2 LTCS Blind Flanges, Carbon Steel LF2 Orifice Flanges, A350 LF2 LTCS Spectacle Blind Flanges, A350 LF2 Screwed / Threaded Flanges, LF2 LTCS Reducing Flanges, ASTM A350 LF2 LTCS Ring Type Joint Flanges (RTJ) etc.

Manufacturer Of A350 LF2 LTCS Plate Flange, A350 LF2 WN Flange, ASTM A350 LF2 CL1 Specification, ANSI B16.5, ANSI B16.47, B16.48, BS4504, BS 10, EN-1092 LTCS Forged Flanges, LTCS A350 LF2 Socket Weld Flanges, LTCS ASTM A350 LF2 Threaded Flanges, LTCS A350 LF2 Slip On Flange, LTCS A350 LF2 Plate Flange, LTCS A350 LF2 Threaded Flange, Carbon Steel ASTM A350 LF2 Low Temp Lapped joint Flanges in Mumbai, India.

What is ASTM A350 LF2 flange?

ASTM A350 LF2 flange is a low-temperature carbon steel flange commonly used in applications requiring resistance to low-temperature environments. These flanges are typically used in the oil and gas industry, where they are used in pipelines, valves & pressure vessels.

What are the properties of ASTM A350 LF2 Flanges?

The properties of ASTM A350 LF2 Flanges include their excellent toughness and ductility at low temperatures. They also have high impact strength & good weldability, making them ideal for low-temperature applications.

What are the advantages of LTCS A350 LF2 Flanges?

The advantages of LTCS A350 LF2 Flanges include their ability to resist low temperatures, which makes them suitable for use in harsh environments. They also have high durability, good weldability & low maintenance requirements, which can help to reduce overall costs.

Standard Specification For LTCS ASTM A350 LF2 / A350 LF2 Industrial Flanges


Specifications : ASTM A350 LF2 / ASME SA350

Dimensions : ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.

Standard : ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.

Material : ASTM A350 LF1, LF2 CL1/CL2, LF3 CL1/CL2

Size : 1/2″ to 48″

Class / Pressure : 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.

Flange Face Type : Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)


Chemical Composition of Carbon Steel ASTM A350 LF2 Flanges

Element Grade LF9 Grade LF2 Grade LF787 Grade LF6 Grade LF3 Grade LF1 Grade LF5
Phosphorus, max 0.035 0.035 0.025 0.025 0.035 0.035 0.035
Manganese 0.40-1.06 0.60-1.35 0.40-0.70 1.15-1.50 0.90 max 0.60-1.35 0.60-1.35
Chromium 0.30 maxᶜ 0.30 maxᵇ˒ᶜ 0.60-0.90 0.30 maxᵇ˒ᶜ 0.30 maxᶜ 0.30 maxᵇ˒ᶜ 0.30 maxᶜ
Sulfur, max 0.040 0.040 0.025 0.025 0.040 0.040 0.040
Carbon, max 0.20 0.30 0.07 0.22 0.20 0.30 0.30
Molybdenum 0.12 maxᶜ 0.12 maxᵇ˒ᶜ 0.15-0.25 0.12 maxᵇ˒ᶜ 0.12 maxᶜ 0.12 maxᵇ˒ᶜ 0.12 maxᶜ
Siliconᴬ …. 0.15-0.30 0.40 max 0.15-0.30 0.20-0.35 0.15-0.30 0.20-0.35
Nickel 1.60-2.24 0.40 maxᴮ 0.70-1.00 0.40 maxᴮ 3.3-3.7 0.40 maxᴮ 1.0-2.0
Copper 0.75-1.25 0.40 maxᴮ 1.00-1.30 0.40 maxᴮ 0.40 max 0.40 maxᴮ 0.40 max
Vanadium 0.03 max 0.08 max 0.03 max 0.04-0.11 0.03 max 0.08 max 0.03 max
Columbium 0.02 max 0.02 maxᴰ 0.02 min 0.02 max 0.02 max 0.02 maxᴰ 0.02 max
Nitrogen …. …. …. 0.01-0.030 …. …. ….

ASTM A350 LF3 Flanges Mechanical Properties

Manufacturer of A350 Lf2 Killed Carbon Steel Flanges and Carbon Steel A350 LF2 Slip On Flanges in Mumbai, browse our range of ASTM A350 Grade LF2 Class 2 Pipe Flange and A350 Gr. LF2 CL.1 Blind Flange online

Grade Minimum Impact Eneragy Permitted for One Specimen only of a Set, ft-lbf[J] Minimum Impact Energy Required for Average of Each Set of Three Specimens, ft·lbf[j]
LF2, Class 1 12 [16] 15 [20]
LF6, Classes 2 and 3 15 [20] 20 [27]
LF1 and LF9 10 [14] 13 [18]
LF3 Class 1 12 [16] 15 [20]
LF 787 Classes 2 and 3 12 [16] 15 [20]
LF3, Class 2 15 [20] 20 [27]
LF6, Class 1 12 [16] 15 [20]
LF5 Class 1 and 2 12 [16] 15 [20]
LF2, Class 2 15 [20] 20 [27]

ASTM A350 LF2 LTCS Pipe Flanges

Forged and Plate Flanges

Products Size
ASTM A350 LF2 LTCS Slip-On Flanges ASTM A350 LF2 LTCS Threaded Flanges Sizes 1/2″ – 48″
Raised Face or Flat Face
ASTM A350 LF2 LTCS Weld Neck Flanges ASTM A350 LF2 LTCS Socket Weld Flanges
ASTM A350 LF2 LTCS Blind Flanges ASTM A350 LF2 LTCS Reducing Flanges
ASTM A350 LF2 LTCS Lap Joint Flanges ASTM A350 LF2 LTCS Plate Flanges
ASTM A350 LF2 LTCS Orifice Flanges ASTM A350 LF2 LTCS Forged Flanges
ASTM A350 LF2 LTCS Ring Type Joint Flanges ASTM A350 LF2 LTCS Square Flanges

LTCS Flange Standards / Types And Pressure Class :

ASME/ANSI B 16.5 Welding Neck Flange, Slip on Flange, Blind Flange, High Hub Blind Flange, Socket Weld Flange, Lap Joint Flange, Threaded Flange, Ring Type Joint Flange
PRESSURE CLASS 150, 300, 400, 600, 900, 1500, 2500
ASME/ANSI B 16.47 Welding Neck Flange, Blind Flange [Series A & B]
PRESSURE CLASS 75, 150, 300, 400, 600, 900
ASME/ANSI B 16.36 Welding Neck Flange, Slip on Flange, Threaded Flange
PRESSURE CLASS 300, 400, 600, 900, 1500, 2500
BS 4504 SEC 3.1 Welding Neck Flange, Hubbed Slip on Flange, Hubbed Threaded Flange, Lapped Pipe End Flange, Plate Flange, Loose Plate Flange, Loose Plate With Weld Neck Flange, Blank Flange
PRESSURE CLASS PN 2.5 TO PN 40
BS 4504[PART 1] Welding Neck Flange, Hubbed Slip-On Hubbed Threaded, Plate Flange, Loose Plate With Weld On Plate Collar, Blank Flange
PRESSURE CLASS PN 2.5 TO PN 400
BS 1560 BOSS Welding Neck Flange, Socket Welding Flange, Slip-On Flange, Blind Flange, Screwed Boss Flange, Lapped Flange
PRESSURE CLASS 150, 300, 400, 600, 900, 1500, 2500
BS10 Welding Neck Flange, Plate Slip-On Flange, Screwed Boss Flange, Slip-On Boss Flange, Blind Flange
TABLE D, E, F, H
DIN FLANGES DIN 2527, 2566, 2573, 2576, 2641,2642, 2655, 2656, 2627, 2628, 2629, 2631, 2632, 2633, 2634, 2635, 2636, 2637,2638, 2673
PRESSURE CLASS PN 6 TO PN 100

Low Temperature Carbon Steel Flange Dimensions

Normal Pipe Size (NPS) Outside Daimeter (O.D.) Of Flange Thickness Of Flanges Diameter of Raised Face Hub at Base Diameter Lengtd Tdru Hub Bore And Diameter Hub at Bevel Diameter Radius of Fillet Socket Deptd
Weld Neck (WN) SORF (Slip-On) NPT (Threaded) SWRF (Socket) Loose (Lap Joint) SORF (Slip-on) SWRF (Socket) Loose (Lap Joint)
O Q R X Y Y Y W B H r Z
1/2 3-1/2 7/16 1-3/8 1-3/16 1-7/8 5/8 5/8 .88 .90 .84 1/8 3/8
3/4 3-7/8 1/2 1-11/16 1-1/2 2-1/16 5/8 5/8 1.09 1.11 1.05 1/8 7/16
1 4-1/4 9/16 2 1-15/16 2-3/16 11/16 11/16 1.36 1.38 1.32 1/8 1/2
1-1/4 4-5/8 5/8 2-1/2 2-5/16 2-1/4 13/16 13/16 1.70 1.72 1.66 3/16 9/16
1-1/2 5 11/16 2-7/8 2-9/16 2-7/16 7/8 7/8 1.95 1.97 1.90 1/4 5/8
2 6 3/4 3-5/8 3-1/16 2-1/2 1 1 2.44 2.46 2.38 5/16 11/16
2-1/2 7 7/8 4-1/8 3-9/16 2-3/4 1-1/8 1-1/8 2.94 2.97 2.88 5/16 3/4
3 7-1/2 15/16 5 4-1/4 2-3/4 1-3/16 1-3/16 3.57 3.60 3.50 3/8 13/16
3-1/2 8-1/2 15/16 5-1/2 4-13/16 2-13/16 1-1/4 1-1/4 4.07 4.10 4.00 3/8 7/8
4 9 15/16 6-3/16 5-5/16 3 1-5/16 1-5/16 4.57 4.60 4.50 7/16 15/16
5 10 15/16 7.5/16 6-7/16 3-1/2 1-7/16 1-7/16 5.66 5.69 5.56 7/16 15/16
6 11 1 8-1/2 7-9/16 3-1/2 1-9/16 1-9/16 6.72 6.75 6.63 1/2 1-1/16
8 13-1/2 1-1/8 10-5/8 9-11/16 4 1-3/4 1-3/4 8.72 8.75 8.63 1/2 1-1/4
10 16 1-3/16 12-3/4 12 4 1-15/16 1-15/16 10.88 10.92 10.75 1/2 1-5/16
12 19 1-1/4 15 14-3/8 4-1/2 2-3/16 2-3/16 12.88 12.92 12.75 1/2 1-9/16
14 21 1-3/8 16-1/4 15-3/4 5 2-1/4 3-1/8 14.14 14.18 14.00 1/2 1-5/8
16 23-1/2 1-7/16 18-1/2 18 5 2-1/2 3-7/16 16.16 16.19 16.00 1/2 1-3/4
18 25 1-9/16 21 19-7/8 5-1/2 2-11/16 3-13/16 18.18 18.20 18.00 1/2 1-15/16
20 27-1/2 1-11/16 23 22 5-11/16 2-7/8 4-1/16 20.20 20.25 20.00 1/2 2-1/8
24 32 1-7/8 27-1/4 26-1/8 6 3-1/4 4-3/8 24.25 24.25 24.00 1/2 2-1/2

Types Of LTCS A350 LF2 Flanges



Physical Properties of ASTM A350 LF6 CL1 Flanges

Physical Properties Cast Carbon Steel Forged
0.25 C Max A216-WCC
0.30/0.35 C Max A216-WCB A105
Low Temperature Steel
0.5 Mo A352-LC1
0.25/0.30 C Max A352-LCB A350-LF2
2.5 Ni A352-LC2
C-MN-Si (0.25 Max) A352-LCC A350-LF3
3.5 Ni A352-LC3
C-MN-Si-V (1.15~1.50 Mn) A350-LF6

Weight Chart of Carbon Steel A350 LF2 Flanges

Loose (Lap Joint) SORF (Slip On) WRNR (Weld Neck) NPT (Threaded) NPS (Nominal Pipe Size) SWRF (Socket Weld) BLRF (Blind)
1 1 2 1 ½ 2 2
2 2 2 2 ¾ 2 2
2 2 3 2 1 2 2
3 3 3 3 3 3
3 3 4 3 3 4
5 5 6 5 2 5 5
8 8 10 8 8 7
9 9 11.5 9 3 9 9
11 11 12 12 11 13
13 13 16.5 13 4 13 17
15 15 21 15 5 15 20
19 19 26 19 6 19 27
30 30 42 30 8 30 47
43 43 54 43 10 43 70
64 64 88 64 12 64 123
105 90 114 90 14 90 140
140 106 140 98 16 98 180
160 130 165 130 18 130 220
195 165 197 165 20 165 285
245 185 225 185 22 185 355
275 220 268 220 24 220 430

ASTM A350 LF2 LTCS Flanges Available Types

LTCS Flanges LF2 LTCS EN 1092-1 Flanges
LTCS BS 4504 Flanges LTCS A350 LF2 Forged Flanges
LTCS A350 LF2 Flanges LTCS LF2 Slip on Flanges
LTCS LF2 Flat Flange Suppliers ANSI LTCS Blind Flange
LTCS A350 LF2 Weld Neck Flanges Dealer LTCS LF2 Socket weld Flanges Exporter
LTCS LF2 Long Weld Neck Flanges Stockholder CS ASTM A350 LF2 Threaded Flanges Distributors
LTCS ASTM A350 LF2 Reducing Flanges LTCS LF2 Ring Type Joint Flanges Manufacturer
LTCS A350 LF2 Orifice Flange ASTM A350 LF2 LTCS Spectacle Blind Flanges
ASME SA350 LF2 LTCS WNRF Flange Carbon Steel ASTM A350 LF2 Low Temperature SORF Flanges
ANSI B16.5 LTCS RTJ Flanges Low Temperature LF2 Screwed Flanges Stockist
ASTM A350 LF2 LTCS Lap Joint Flanges ASME SA350 LF2 LTCS BLRF Flange
Carbon Steel Low Temperature LF2 Raised Face Flanges Carbon Steel ASTM A350 LF2 Low Temperature Nipoflange
A350 LF2 LTCS Square Flanges ASME SA350 LF2 LTCS SWRF Flange
Steel Tongue & Groove Flanges Carbon Steel A350 LF2 Low Temperature Male & Female Flanges
A350 LF2 LTCS DIN Flanges LTCS LF2 ASME B16.5 Flanges

Carbon Steel Low Temperature AISI, ASME, DIN, BS, EN Flanges Application

ASTM A350 LF2 Pipe Flanges are known to deliver exceptional performance and are generally developed for meeting the demands. We offer a broad range of ASTM A350 LF2 LTCS Flanges through a worldwide network of stock-keeping branches. These ASTM A350 LF2 Carbon Flange is use in various industries like :

  • LTCS Flanges uses in Oil and Gas Pipeline
  • ASTM A350 LF2 LTCS Pipe Flanges uses in Chemical Industry
  • A350 LF2 LTCS Flanges uses in Plumbing
  • LTCS ASTM A350 LF2 Flange uses in Heating
  • ASTM A350 LF2 Plate Flanges uses in Water Supply Systems
  • ASTM A350 LF2 LTCS Forged Flanges uses in Power Plant
  • Carbon A350 LF2 Low Temperature Flanges uses in Paper & Pulp Industry
  • A350 LF2 LTCS Flanges uses in General Purpose Applications
  • ASME SA350 LF2 LTCS Industrial Flanges uses in Fabrication Industry
  • Low Temperature LF2 Flanges uses in Food Processing Industry
  • ANSI LTCS A350 LF2 Flanges uses in Structural Pipe
